ZL15F Mini Wheel Loader:
Yunnei 490 Air Pump Diesel Engine (42kW), Single joystick mechanical pilot control, Hydraulic torque convertor and transmission, Wheel Reducer Axle
Optional attachments : 1.5m3 large bucket, 3.2m dumping height, quick hitch, pallet fork, wood/grass grapple, snow blade/bucket, road sweeper, 4-in-1 bucket
ZL15F Wheel Loader Main Specifications:
Item | Parameters |
Rated Load | 1500 kg |
Total Weight | 3600 kg |
Rated Bucket Capacity | 0.8m3 |
Max. Breakout Force | ≥ 32 KN |
Max. Climving degree | 30° |
Dumping Height | 3200 mm |
Dumping Reach | 900 mm |
Dump Time | 3.5 s |
Boom fall Times | 3 s |
Overall Dimensions (L x W x H) | 5250*1800*2800 mm |
Bucket dimensions | 1750*830*420mm |
Min. Turning Radius | 3000 mm |
Model | Yunnei 490 Air Pump Diesel Engine |
Rated Power | 42Kw |
Rated Speed | 2400 rpm |
Model of Axle | ISUZU type Drive Axle |
Wheel Tread | 1350 mm |
Wheel Base | 2070 mm |
Drive type | 4-WD Hydraulic transmission |
Fuel Tank Capacity | 70 L |
Brake type | Drum Brake |
Tyre | 20.5-16 |
