Item | Parameters |
Rated Load | 5000 kg |
Engine Model | Shanghai Diesel SC11cb220g2b1 |
Rated Power | 162kW/2200RPM |
L*W*H | 7600mm*3000mm*3350mm |
Bucket Width | 3000mm |
Wheel Base | 2760mm |
Tread Width | 2250mm |
Dumping Height | 3200mm |
Dumping Reach | 1250mm |
Operation Weight of machine | 16500kg |
Bucket capacity | 3.0 CBM |
Max climbing Gradient | 28 |
Turning angle | 35° |
Turning radius | 6650mm |
Max Breakout Force | 145kN |
Total Cycling time | ≤6.8s |
Hydraulic Cycling Time | ≤12.55s |
Travel Speed I | 11.5 km/h |
Travel Speed II | 38km/h |
Reverse Speed | 16km/h |
Air Conditioner | Option |
Tyre Size | 23.5-25 * 4 pcs |
